Heavy Hammer Crushers

What is Heavy Hammer Crusher?

STCrusehers heavy hammer crusher is designed based on PC series crusher. According to the user feedback information and the development of the crushing industry, combined with the experimental data of our company to develop a new type of crusher. Compared with other hammer crusher, the alloy composite hammer head has the characteristics of high wear resistance, large moment of inertia and high kinetic energy of the rotor. It has the characteristics of large particle size, high crushing ratio and low maintenance cost. With an hourly production of 50 tons to 5000 tons, this series of crushers is becoming the preferred equipment for the crushing industry.

Size and Capacity of Heavy Hammer Crusher

It has the characteristics of large particle size, high crushing ratio and low maintenance cost. With an hourly production of 50 tons to 5000 tons, this series of crushers is becoming the preferred equipment for the crushing industry.

The main working part of the PCZ type heavy hammer crusher is a rotor with a hammer (also called a hammerhead). The rotor consists of a main shaft, a disc, a pin and a hammer. The motor drives the rotor to rotate at high speed in the crushing chamber. The material is fed into the machine from the upper feeding port, and crushed by the hammer. In the lower part of the rotor, a sieve plate is arranged, and the size of the crushed material smaller than the mesh size is discharged through the sieve plate, and the material larger than the mesh size is remained on the sieve plate and continues to be struck and ground by the hammer, and discharged through the sieve plate.
